This page showcases sample designs, Mechanical Computer-Aided Design (MCAD), and engineering projects created by DYNEDE Ltd.

Here you will find 2D and 3D models developed using CAD, along with technical descriptions and applications..

Robo Base - 3D Model

This is a 3D designed robotic base created in CAD. Application: Used as the main chassis for mobile robots and automation systems. Material: Aluminum Alloy 6061. Features include precision mounting holes, integrated cable routing channels, and structural reinforcements for heavy loads.

Rotor Assembly - 3D Model

High precision rotor assembly designed in CAD. Application: Used in electric motors and rotating machinery for torque transmission. Material: Hardened Steel Alloy. Features: Dynamic balancing, bearing seats with H7 tolerance, and keyways for secure shaft mounting.

UST Component - 3D Model

Custom UST mechanical component modeled in CAD. Application: Used in industrial automation and precision mechanical assemblies. Material: Stainless Steel 304. Features: Tight tolerances +/- 0.05mm, optimized geometry for CNC manufacturing.

UST Component - 3D Model

Custom UST mechanical component modeled in CAD. Application: Used in industrial automation and precision mechanical assemblies. Material: Stainless Steel 304. Features: Tight tolerances +/- 0.05mm, optimized geometry for CNC manufacturing.
